Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: YUANHENG
  • Model Number: Electric Gear Pmp
  • Theory: Rotary Pump
  • Structure: Gear Pump
  • Usage: Oil
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: Diesel
  • Pressure: Low Pressure
  • Application: Metering, gear oil pump
  • structure: electric gear pump
  • size: 20-100mm
  • Flow: 9-960L/min
  • gear material: steel, stainless steel, bornze
  • casing material: cast iron, stainless steel
  • Power range: 0.37Kw-22Kw
  • voltage: 110v, 220v, 380v, 440v
  • max pressure: 1.45Mpa
  • sample: electric gear pump yes

Packaging & Delivery

Packaging Details export standard cartons or wooden cases
Delivery Time Shipped in 7 days after payment

Electric Pump

Gear Oil Pump

Electric Gear Pump

Product Description

Gear Pump Introduction:





Our extensive gear pump range provides solutions for diesel, kerosene, bio-diesel, lubricant, engine oil, frying oil etc



When selecting a gear oil pump,  you need to decide the electric gear pump size, flow rate, and transferring liquid viscosity.



Size of our gear pump options are from 3/4" to 6", with flow rate from 9LPM to 1200LPM



Material of pump body can choose cast iron, stainless steel according to different requirements

 PIUSI VISCOMAT ELECTRIC GEAR PUMP, GEAR OIL PUMP, ELECTRIC PUMP, ELECTRIC GEAR OIL PUMP, OIL GEAR PUM
Detailed Information



YHJYB-1 Electric Gear Oil Pump



 PIUSI VISCOMAT GEAR OIL PUMP

Gear electric oil transfer pump performs well during medium pressure oil transfer, and also delivers good flow rates in high pressure systems

Self-priming Viscomat oil transfer pump

Smooth flow & high suction capacity

Incorporated bypass valve & NBR lip seal

 Aluminium body & sintered steel gears

Flow rate: 9-15ltr per min

1” F BSP inlet/outlet

Continuous running

Voltage: 220V Single Phase

             380V Three Phase

---------------------------------------------------------------------------------------

YHJYB-2 Thermal Gear Pump

electric pump



♦ The electric gear pump is designed for high temperature frying oil

♦ Also can be used for diesel, bio-diesel, engine oil and other lubricants

♦ Max temperature: 200℃

♦ Can be installed into the frying machine for frying oil circulation

♦ Thermal overheat protection makes the pump long using life

♦ Pump body material can be cast iron, or stainless steel

♦ 1" BSPF inlet & outlet with low flow rate at 15LPM

♦ Motor power of 370W, with speed of 1450rpm

♦ Voltage: 220V, 50Hz

---------------------------------------------------------------------------------------

 Portable Gear Oil Pump

ELECTRIC PUMP, ELECTRICL GEAR PUMP, GEAR OIL PUMP

♦ Awesome self-priming portable close-coupled rotary gear pumps

It may be used for pumping oily liquids such as diesel, biodiesel, kerosene, and warm vegetable oil or cold vegetable oil if started up properly

♦ Pump attached to the motor by a shaft

♦ Pump body materials can be cast iron, or stainless steel

♦ 4 models with flow rate options of 30LPM, 50LPM, 75LPM and 100LPM

ModelYHWCB-30YHWCB-50YHWCB-75YHWCB-100
Inlet&Out Size3/4"3/4"1"1"
Flow Rate30LPM50LPM75LPM100LPM
Delivery Head30m30m30m30m
Motor Power370W550W750W1100W
Motor Speed2800rpmror 1400 rpm
Voltage

110V, 60Hz, 220V, 50Hz(60Hz) single phase

380V, 415V 50Hz three phase

Body Material

Cast Iron, Stainless Steel

Gear Material

Steel, Brass, Stainless Steel

Bypass valve

Option



---------------------------------------------------------------------------------------

Lubricant Gear Oil Pump

ELECTRIC PUMP, GEAR PUMP, GEAR OIL PUMP, ELECTRIC GEAR PUMP

♦ For pumping thick oils such as lubricanting oil(motor oil), vegetable oil, animal oil and ligher oils such diesel fuel or biodiesel

♦ Continuous duty cycle

♦ Heavy duty positive displacement internal gear structure

♦ Cast iron pump body with sintered steel gears

♦ Incorporated with bypass valve



ModelYHYTB-40YHYTB-70
Inlet&Outlet Size3/4"1"
Flow Rate40LPM70LPM
Pressure3bar3bar
Motor Power550W750W
Motor Speed2800rpm2800rpm
Voltage

110V, 60Hz, 220V, 50Hz(60Hz) single phase

380V, 415V, 50Hz, three phase

Self Priming

Yes

Bypass Valve

Yes



---------------------------------------------------------------------------------------




Packing&Shipping&Pay

 Packing Information for electric pump, gear oil pump, electric gear pump, PIUSI VISCOMAT GEAR PUMP





Company Information

 We manufacturer electric pump, gear oil pump, electric gear pump, PISUI VISCOMAT GEAR OIL PUMP





FAQ





FAQ.

Frequently Asked Questions

 1. Electric Pump

2. Gear Oil Pump

3. Electric Gear Pump



1. When can I get the quotation ?

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.



2. How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality.
If you need the samples, we will charge for the sample cost .But the sample cost can be refundable from future orders.



3. What is MOQ?

1PC for regular products



4. What is Payment?

T/T, Western Union, Paypal, Moneygram, Escrow. For LC, please confirm with us with exact order.



5. How long can I expect to get the order?

After receipt of your payment.

When delivery by express, it will take about 5-7 days to your door.

If delivery by normal air delivery, it will take about 7-10 days to your local air port.

By sea, it will take about 7 to 60 days depends on your destination port.



6. What about the lead time for mass production?

Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to15 days. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.



7. What is your terms of delivery?

We accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or cost effective for you.



 8. How long is the warranty?

According to international standards, products in standard operation is 1 year(except wearable parts & seals). For wearable parts&seals, we provide small quantity free
